| Menyoroti: | kabel serabut serat,kabel patch serat sc |
||
|---|---|---|---|
Konektor: SC, LC, FC, ST, E2000, MTRJ, MU, MPO, DIN
Jenis: Singlemode atau Multimode
Ujung-muka Ferrule: UPC, APC
Diameter kabel: 3.0mm, 2.0mm, 0.9mm, 0.25mm
Panjang kabel: 1M, 3M, 5M, disesuaikan
Cable Jacket: PVC, LSZH
Inti: Simplex, Duplex
Penggunaan: Peralatan pengujian, FTTX + LAN, CATV serat optik, sistem komunikasi optik,
Telekomunikasi
Barang | Satuan | FC, SC, LC | ST, MU | MT-RJ, MPO | E2000 | ||||||||
SM | MM | SM | MM | SM | MM | SM | |||||||
PC | UPC | APC | PC | UPC | PC | PC | PC | UPC | PC | PC | UPC | ||
Kerugian penyisipan (khas) | dB | ≤0.3 | ≤0.2 | ≤0.3 | ≤0.2 | ≤0.3 | ≤0.2 | ≤0.2 | ≤0.3 | ≤0.2 | ≤0.2 | ≤0.3 | ≤0.3 |
Mengembalikan kerugian | dB | ≥45 | ≥50 | ≥60 | ≥30 | ≥45 | ≥50 | ≥30 | ≥45 | ≥50 | ≥35 | ≥55 | ≥75 |
Beroperasi panjang gelombang | nm | 1310.1510 | 1310.1510 | 1310.1510 | 1310.1510 | ||||||||
Exchengeability | dB | ≤0.2 | ≤0.2 | ≤0.2 | ≤0.2 | ||||||||
Getaran | dB | ≤0.2 | ≤0.2 | ≤0.2 | ≤0.2 | ||||||||
Suhu Operasional | ° C | -40 ~ 75 | -40 ~ 75 | -40 ~ 75 | -40 ~ 75 | ||||||||
Suhu penyimpanan | ° C | -45 ~ 85 | -45 ~ 85 | -45 ~ 85 | -45 ~ 85 | ||||||||
Diameter Kabel | mm | φ3.0, φ2.0, φ0.9 | φ3.0, φ2.0, φ0.9 | φ3.0, φ2.0, φ0.9 | φ3.0, φ2.0, φ0.9 | ||||||||
-Full spesifikasi, FC, SC, ST, LC, MTRJ, E2000, DIN, D4, SMA, dll.
Rakitan -Simplex dan Duplex tersedia
-Singlemode dan multimode tersedia
-PC, UPC dan APC polishing tersedia
Kabel patch -Hybrid tersedia atas permintaan
-Konversi tersedia (Jenis pita / tipe bundel)
-Pigtail tersedia
-Loopback tersedia
- Panjang disesuaikan berdasarkan permintaan
-100% diuji sebelum pengiriman
