Detail produk:
Syarat-syarat pembayaran & pengiriman:
|
| Length: | 1m or customized | Sertifikasi: | RoHS,ISO9001 |
|---|---|---|---|
| Cable color: | Colors | Connector: | SC,FC,LC |
| Ferrule End-face: | APC | Cable diameter: | 0.9mm/2.0mm/3.0mm |
| Return loss: | >50dB | Fiber Count:: | 4/6/8/12 Fibers |
| Menyoroti: | 0.9mm Fiber Optic Pigtail,OS2 Fiber Optic Pigtail,Pigtail Mode Tunggal OS2 |
||
Parameter
| Parameter | Serat mode tunggal | Serat Multimode | ||
| PC | UPC | APC | PC | |
| Kerugian Penempatan (dB) | ≤ 0.3 | ≤ 0.2 | ≤ 0.3 | ≤ 0.3 |
| Kehilangan Pengembalian ((dB) | ≥45 | ≥ 50 | ≥ 60 | ≥ 20 |
| Kemampuan bertukar (dB) | ≤ 0.2 | |||
| Hidup plug-pull ((waktu) | > 1000 | |||
| Suhu operasi ((°C) | -40 ~ +75 | |||
| Suhu penyimpanan ((°C) | -45 ~ +80 | |||
| Model serat | φ0.9mm, φ2.0mm, φ3.0mm | |||
